– Lithium Iron Phosphate (LifePO4) Battery Type – 5.12kWh Usable capacity – 100 Ah Nominal capacity @ 0.2C – 51.2 VDC Nominal Voltage – Operating Voltage Range : 45.6 VDC to 56.16VDC – Operating Temp Range : 0°C to 55°C – Protection : Over-voltage | Under-voltage | Short circuit | Dust and water resistant – Lifespan : 6000 cycles @ 80% DOD / 25°/0.5C / 60% EOL – Dimensions : 520 x 470 x 141.5 mm (L x W x H) – Weight : 47.2kg
Charging / Discharging
– Bulk Charging Voltage : 56.1 VDC – Float Charging Voltage : 55 VDC – Max Charge / Discharge Current: 100A – Standard Charge /Discharge Current : 20A-50A – Max Charge / Discharge Power: 5000W – Discharge Voltage Minimum : 45.6V – Under-voltage Cut-out : 44.8 VDC – Over-voltage Cut-out : 58.4 VDC
What's included?
1 x 51.2v 100Ah (5.12kWh) Lithium (LiFeP04) Battery 1 x Installation Manual 1 x Wall Mounting Brackets 1 x Set of Battery Cables (1m long each, quick connect terminal and 10mm terminal) 1 x Pair of Quick Connectors (if using in parallel)
