EVE 3.2V 105Ah Lithium Ion Battery-Set of-Carton of 8
EVE 3.2V 105Ah Lithium Ion Battery-Set of-Carton of 8
Regular price
R 1,350
Regular price
Sale price
R 1,350
Unit price
/
per
Model : LF105
Nominal Capacity : 105Ah
Nominal Voltage : 3.2v
Weight : 1.98kg +- 60g
Dimensions : 130.3 x 36.7 x 200.5mm
Standard Charge/Discharge Current : 0.5C/0.5C
Maximum Continuous Charge/Discharge Current : 1C/1C
Pulse Charge/Discharge Current(30s) : 1C/3C
Charging Cut-Off Voltage : 3.65v
Discharge Cut-Off Voltage : 2.5V
Charging Working Temperature : 0℃~65℃
Discharging Working Temperature : -20℃~60℃
Initial Internal Resistance : 0.32mΩ +- 0.05mΩ
Tests conducted on cells:
These 3.2V 105Ah Lithium Ion battery cells have passed all of the safety tests (overcharge, overdischarge, over temperature, short circuit, drop, crush, needle puncture).
That means even under these severe conditions these battery cells do not catch fire, explode or leak.
Notes:
The cells are supplied with M6 studs laser welded onto the cells.
No other accessories are supplied. Just the cells.
The battery is suitable for DIY or battery builders with experience.
Application:
Solar energy storage, solar power system, UPS supply, Engine starting battery, Electric bicycle/motorcycle/scooter, Golf trolley/carts, RV, EV, Caravan..
